Category | Descriptions | ||
Model | No. | Q500S Series S12 Mini PC | |
Processor System | CUP | Intel Celeron Kaby Lake 3865U Dual Core Processor 1.8GHz, 2M Cache Intel Celeron Kaby Lake 3965U Dual Core Processor 2.2GHz, 2M CacheIntel Core i3 7100U Dual Core Processor 2.4GHz, 3M Cache Intel Core i5 7200U Dual Core Processor 2.5GHz Up to 3.1GHz, 3M Cache Intel Core i7 7500U Dual Core Processor 2.7GHz Up to 3.5GHz, 4M Cache | |
CUP TDP | 15W | ||
Memory | 1 x DDR4 SO-DIMM Socket (Up to 32G, 2133MHz) | ||
Chipset | By CPU | ||
Graphics | 3865U 3965U Intel HD Graphics 610 7100U 7200U 7500U Intel HD Graphics 620 | ||
LAN Chipset | 2 x Realtek Gigabit LAN | ||
Audio | Realtek ALC662 HD Audio | ||
Watch Dog | Yes | ||
Front I/0 | Power Button | 1 | |
LED | 1 x Power LED, 1 x HDD LED | ||
USB | 2 x USB2.0, 2 x USB3.0 | ||
Rear I/O | Power | 1 x DC Jack | |
Video Output | 2 x HD | ||
LAN | 2 x RJ-45 Port for Gigabit LAN | ||
USB | 2 x USB 3.0 | ||
Audio | 2 (Line-out, Mic-in) | ||
Type | 1 x 2.5-inch HDD/SSD | ||
1 x M.2 slot for NVMe SSD (M.key, Type: 2280) | |||
M.2 | 1 x M.2 for SSD (M key, 2280) | ||
M.2 | 1 x M.2 for Wi-Fi (E key, 2230) | ||
GPIO | 1 x 2.0 Pitch Header (Option) | ||
SIM Card Slot | 0 | ||
USB | 1 | ||
DC-in | 1 (Option) | ||
VGA | 1 (Option) | ||
Automatically Boot Jumper | 1 | ||
Power Adapter | 12V3A | ||
DC Jack | 5.5mm, 2.5mm | ||
Environmental | Operating Temp | 0°C~50°C | |
Non-Operating Temp | -20°C~80°C | ||
Humidity | 10%~90% | ||
Material | Aluminium Alloy | ||
Dimension | 129 x 128 x 39mm | ||
Weight | 0.75kg | ||
Mounting | VESA Mounting Bracket | ||
Packaging Dimension | 261 x 218 x 75mm | ||
Kensington Lock | Support | ||
Cooling Mode | With Fan | ||
OS Support | Win 10/7,Linux | ||
